Schumacher DSR123 ProSeries Wheeled Battery Starter/Charger
- Charges standard, deep cycle, AGM and gel cell battery types
- Easy operation with digital display, LED indicators and touch pad controls for voltage, percent of charge, alternator, and user-controlled start/stop interface
- 10-50 Amp boost mode ramps up the voltage, sending a quick burst of energy that can quickly bring deeply discharged batteries back to life
- Wheeled design with retractable handle provides roll-around convenience
- Dual 12V/24V operation with 250 Amp output at 12V and 150 Amp output at 24V
- 4 Amp trickle charge keeps stored, lead-acid batteries charged, and charges and maintains small batteries
- Fully automatic microprocessor control prevents over-charging by monitoring the battery and automatically switching to maintenance mode when fully charged
- Memory saver mode provides a 12V DC port connection and 15A fuse for maintaining or saving vehicle settings while changing the battery
- Flash reprograming power supply provides consistent and stable power at OEM specific voltage up to 100 Amps
- Streamlined design with rugged construction that’s safe for indoor or outdoor use
Features and Specs
Features
- Charges standard, AGM and Gel and deep-cycle batteries
- 250A (12V)/150A (24V) Engine Start – powerful enough for SUVs, trucks and large engines
- 1050A (12V) 1030A (24V) Boost mode – quickly brings deeply discharged battery back to life
- Microprocessor-controlled – automatically adjusts amperage rate, to charge and maintain
- Multi-stage charging – for added precision, safety and battery life
- Float mode monitoring – maintains optimum battery charge
- Reverse hook-up protection
- Digital display, LED indicators and push-button controls
- Start/Stop interface
- Extra-long output cables – 17 ft. total reach
- Retractable handle
- Safe for outdoor use
- Schu Eco Energy – meets the highest industry standards
- DOE compliant
- Contents: (1) DSR123 battery charger (4) Cable clamp cleats (4) Screws (1) Manual
Specifications
- Battery Type: Standard, AGM, Gel, Deep-Cycle
- Input Voltage: 120V AC
- Input Current: 8A cont., 60A int.
- Output Voltage: 12/24V
- Output Current: 4/15A cont; 30/50/150/250A int
- Dimensions: 16.25 × 20.5 × 33.63 in
- Weight: 60 lb
- Safety Certifications: UL ULC
Warranty: 2 Years
